Description
Combination of battery-protected and surge-only outlets reserves power capacity for connected equipment that requires battery back-up. Dataline Surge Protection provides protection of connected equipment on the data lines. Power conditioning protects connected loads from surges, spikes, lightning, and other disturbances. Audible alarms delivers notification of changing utility power and UPS conditions. Automatic restart of loads after UPS shutdown upon the return of utility power for exceptional convenience. Automatic battery self-test ensures early detection of a battery that needs to be replaced. System VA: 500 VA; Backup Time at Half Load: 13.9 min @ 150 W; Automatic Voltage Regulation (AVR): No; Battery Recharge Time: 8 h.
Features
- Battery-protected and surge-only outlets.
- Dataline Surge Protection.
- Power conditioning.
- Audible alarms.
- Automatic restart of loads after UPS shutdown.
- Automatic battery self-test.
- LED status indicators.
- Battery replacement without tools.
- Transformer-block spaced outlets.
Specifications
| Automatic Voltage Regulation (AVR) | No |
|---|---|
| Backup Run Time | 15 min |
| Backup Systems Alarm(s) | Audible |
| Backup Time at Full Load | 2.4 min @ 300 W |
| Backup Time at Half Load | 13.9 min @ 150 W |
| Battery Recharge Time | 8 h |
| Color(s) | Beige |
| Compliance Standards | cUL Listed; FCC Class B Certified; UL Listed |
| Connected Equipment Guarantee/Warranty | $100,000 Equipment Protection Policy |
| Connector/Port/Interface | DB9; RS232; USB |
| Cord Length | 6 ft |
| Depth | 11.2" |
| Disclaimer Statement | Run Time based on a load of 150 W. |
| Emergency Power Off (EPO) | No |
| Global Product Type | Backup Systems |
| Height | 6.5" |
| Input Frequency | 50-60 Hz |
| Joules Of Surge Protection | 480 J |
| Number of Outlets | 6 |
| Number of Outlets/Type | 3 UPS/Surge; 3 Surge Only |
| Post-Consumer Recycled Content Percent | 0% |
| Pre-Consumer Recycled Content Percent | 0% |
| Product Biodegradability in Days | 0 |
| React Time | Instantaneous |
| System VA | 500 VA |
| Telephone/Internet Protection | Fax; Modem; Phone |
| Total Recycled Content Percent | 0% |
| Width | 3.6" |
